High Efficiency Liquid Tank Air Filter

Jul 11, 2024

The High Efficiency Liquid tank Air Filter can be divided into a side liquid tank filter and a top night tank filter, which have certain differences in characteristics and uses.The characteristics of the side liquid tank filter mainly include the following points.It can simultaneously realize the three treatments of particles, algae and dust, that is, it has the composite function of three treatment units.It uses horizontal rotary pressure difference for automatic cleaning and filtration.It has low energy consumption and is generally used in conjunction with power equipment.

The uses of the side liquid tank filter mainly include: used for filtering water treatment equipment in industrial and urban sewage treatment plants, suitable for various industrial and urban sewage, especially for the treatment of oily sewage.

As for the top night tank filter, it is an automatic filtering and cleaning device, usually used on the top of the filter bed. Its main characteristics are good cleaning effect, no secondary pollution, simple operation, short cleaning time, no need to stop water during the cleaning process, and can be completed without stopping the machine.

The main difference between the two is that the side liquid tank filter may be more complicated in filtering effect and cleaning method, while the top night tank filter pays more attention to cleaning effect and simplicity of operation. The specific filter to be used needs to be determined according to actual needs and environment.

----------------------------How to choose a tank filter? When choosing, you need to consider the following factors----------------------------

Filtration accuracy: Choose the appropriate filtration accuracy according to actual needs, usually determined by the type of liquid and the size of impurities.

Filtration area: The larger the filtration area of the tank filter, the better the filtration effect. Therefore, when choosing a ulpa air purifier, the actual use area of the filter should be considered.

Filtration efficiency: The higher the filtration efficiency of the tank filter, the more impurities can be filtered out. Therefore, when choosing a tank filter, you should consider whether its filtration efficiency meets actual needs.

Material: The material of the tank filter has an important impact on the service life and performance. Generally speaking, using high-quality materials can improve the durability and efficiency of the filter.

Safety: When choosing a ulpa filter air purifier, you should pay attention to its safety performance and safety standards.

Flow and size: Choose a suitable tank filter according to the flow required by the equipment and the size of the tank.

----------------------------Based on the above factors, here are some suggestions----------------------------

Choose the appropriate filtration accuracy according to the type of liquid and the size of the impurities.

Consider the actual use area and choose a tank filter with sufficient filtration area.

Refer to the manufacturer's recommendations and specifications to choose a ulpa tank filter that meets safety standards.

Consider the flow rate and size of the ulpa tank filter to ensure that it can meet the needs of the equipment.

When using a tank filter, regular inspection and maintenance are very important to ensure its long-term stable working condition.

----------------------------Daily maintenance details of high-efficiency tank air filters----------------------------

During the transportation and movement of the filter, it should be handled with care, and no violent collision or vibration is allowed.

Pay special attention to the installation of the high-efficiency liquid tank air filter. The installation direction must not be wrong. The connection between the filter and the frame must not have leakage, deformation, damage, or glue leakage. After the filter is installed, the inner wall must be cleaned.

Observe the filter carefully and wipe the filter with a white silk cloth to check for leaks.

Before installing the high-efficiency liquid tank air filter, the clean room must be cleaned and wiped. If there is dust inside the purification air conditioning system, it should be cleaned and wiped again to meet the cleaning requirements. If the high-efficiency filter is installed in the technical mezzanine or ceiling, the technical layer or ceiling should also be cleaned and wiped.

During the transportation and storage of the high-efficiency liquid tank air filter, it must be strictly implemented in accordance with the standards.

The packaging of the high-efficiency liquid tank air filter must be unpacked on site. Before unpacking, check whether the packaging is damaged. After unpacking, check the filter to see if the appearance is damaged. Measure the side length and diagonal of the filter to see if they meet the requirements, whether the outer frame is rusted, and whether the product certificate and technical parameters are correct.

For high-efficiency filters above level 100, strictly implement the provisions of the "Clean Room Construction and Acceptance Specifications" to detect leaks in high-efficiency filters.

When installing the filter, the arrow direction must be consistent with the airflow direction. If it is installed vertically, the hepa ulpa filter paper folds must be perpendicular to the ground.

For primary flat-plate and folding filters, it should be noted that the galvanized mesh surface should be in the direction of the back of the air outlet; the installation direction of the bag filter should make the length of the filter bag perpendicular to the ground, not parallel to the ground.

Primary and medium-efficiency air filters usually need to be replaced after about 2 months of use. The replaced hepa ulpa material can be placed in water with detergent for cleaning and reused after drying. It should be noted that it must be replaced after rinsing twice, and it should be dried naturally, and it cannot be placed in the sun to dry.

The use of bag filters can be used for 3-4 months if it is operated for an average of 8 hours a day.

For sub-high efficiency filters, under normal use conditions (average 8 hours a day, continuous operation), they should also be replaced after 5-6 months of use.

It is recommended to install a differential pressure gauge in front of the filter so that the working status of the filter can be known at any time. If the differential pressure value of the coarse filter exceeds 250Pa, it should be replaced immediately. The differential pressure of the medium efficiency filter cannot exceed 330Pa, and the differential pressure of the sub-high efficiency filter cannot exceed 400Pa. For medium efficiency and sub-high efficiency filters, they cannot be reused.

If the high efficiency liquid tank air filter is damaged, it needs to be replaced. When the differential pressure exceeds 450Pa and the air flow velocity on the outlet surface is reduced to the minimum, the primary and medium efficiency filters can be replaced first. If there is no change, the high efficiency filter needs to be replaced. If these conditions do not occur, the high efficiency filter should be replaced once every 1-2 years.

When replacing the filter, the primary and medium efficiency filters can be replaced without stopping the fan, while the high efficiency filter must stop the fan before it can be replaced. During the use of primary and medium efficiency filters, it is advisable to keep the wind speed below 2.5m/s. The wind speed of sub-high efficiency and high efficiency filters should not exceed 1.5m/s.

After the filter is installed, it must be connected to the frame to ensure airtightness.

Determine which filter to use based on the on-site environment. For example, in high humidity and high temperature environments, use high temperature and high humidity resistant air purifier ulpa.

For biological clean rooms and medical clean rooms, filters with stainless steel or aluminum alloy frames should be selected. Filters with wooden frame boards should not be used to prevent the generation of microorganisms and affect the product's qualification.

Before installing various air filters and high-efficiency air filters, it is not allowed to tear or open the packaging bags or packaging films by hand; the air filters should be stored strictly in accordance with the direction standards marked on the high-efficiency filter packaging box; during the transportation of high-efficiency air filters, they should be handled and placed gently to avoid severe vibration and collision.

For high-efficiency liquid tank air filters, the installation direction must be correct: when using corrugated plate combination hepa and ulpa filters for vertical installation, the corrugated plate must be perpendicular to the ground; the connection between the filter and the frame in the vertical direction is strictly prohibited from leakage, deformation, damage and glue leakage, etc. After installation, the inner wall must be kept clean, free of floating dust, oil, rust and debris.

Before installing the High Efficiency Liquid tank Air Filter, it is required to unpack and inspect the appearance at the installation site, including: whether the filter paper, sealant and frame are damaged; whether the side length, diagonal and thickness dimensions meet the requirements; whether the frame has burrs and rust (metal frame); whether there is a product certificate, and whether the technical performance meets the design requirements.

As a fine technology product, the air filter is easily damaged during transportation and installation, so every step of the transportation and installation of the air filter must be carried out in accordance with strict requirements. After the air filter has been used for a period of time, because too much dust is captured, the efficiency and resistance will decrease. If the air supply effect is far from meeting the requirements, the air filter should be replaced in time.
