Mini-pleated Panel HEPA Filters
Mini-pleated Panel HEPA Filters(also named Absolute Filters) are designed for the air-intake and extract systems of those critical applications where high-efficiency filtration is necessary and they will give protection to the sub-micron level. These HEPA filters are normally used as final filters.
Product Introduction
Snyli Environmental Technology (Shandong) Co., Ltd. is one of the most reliable manufacturers and suppliers of mini-pleated panel hepa filters in China. With abundant experience, we warmly welcome you to wholesale advanced mini-pleated panel hepa filters from our factory. For price consultation, contact us.
Products Description
Mini-pleated Panel HEPA Filters, also called MICROPLEAT filters, are one kind of HEPA filters, which efficiency reach to 99.99% to 99.999%, are used for cleanroom HVAC system final filtration, feature a micro-glass media in a full range of materials and configurations to install in all types of housings and framing systems, from clean room ceiling grids and modules to benches and self-contained equipment.
As a mini pleat HEPA filter manufacturer, we test glass fiber media/PTFE to make sure the airflow rate and pressure drop requirement firstly, then we test finished products to make sure the efficiency. Strict "quality control" is enforced throughout the manufacturing process and on completion, each individual Filter is tested and certified for use.
Products Specifications
● Series: Mini-pleat
● Frame: Aluminium & Galvanise
● Separators: Hot melt
● Media: Glass fibre/Polytetrafluoroethylene (PTFE)
● Sealan: Polyurethane
● Clapboard: No clapboard
● Temperature: 700ºC
●Humidity: 100% RH
● Efficiency: MPPS: >99.995% (H13);
DOP: >99.97% @ 0.3µm
Technical Data
E12, H13, H14(Standard Airflow)
Model | Actual Size W×L×D（mm） | Air Flow (m³/h) | Initial P.D. | Final P.D. *Proposed Value |
H4BX1-70L5-WB1 | 484×484×70 | 630 | 249Pa *Face velocity 0.85m/sec | 500pa |
H4PT2-70L5-WB1 | 630×630×70 | 1100 | ||
H4BX3-70L5-WB1 | 570×1170×70 | 1000 | 110Pa *Face velocity 0.45m/sec | 220Pa |
H4PT4-70L5-WB1 | 1170×1170×70 | 2100 | ||
H4BX1-90L5-WB2 | 484×484×90 | 630 | 220Pa *Face velocity 0.85m/sec | 440Pa |
H4PT2-90L5-WB2 | 630×630×90 | 1100 | ||
H4BX3-90L5-WB2 | 570×1170×90 | 1000 | 98Pa *Face velocity 0.45m/sec | 200Pa |
H4PT4-90L5-WB2 | 1170×1170×90 | 2100 |
E12, H13, H14(High Airflow)
Model | Actual Size W×L×D（mm） | Air Flow (m³/h) | Initial P.D. | Final P.D. *Proposed Value |
H4BX1-70L5-WD1 | 484×484×70 | 930 | 249Pa *Face velocity 0.85m/sec | 500pa |
H4PT2-70L5-WD1 | 630×630×70 | 1620 | ||
H4BX3-70L5-WD1 | 570×1170×70 | 1000 | 98Pa *Face velocity 0.45m/sec | 200Pa |
H4PT4-70L5-WD1 | 1170×1170×70 | 2100 | ||
H4BX1-90L5-WD2 | 484×484×90 | 930 | 220Pa *Face velocity 0.85m/sec | 440Pa |
H4PT2-90L5-WD2 | 630×630×90 | 1620 | ||
H4BX3-90L5-WD2 | 570×1170×90 | 1000 | 78Pa *Face velocity 0.45m/sec | 160Pa |
H4PT4-90L5-WD2 | 1170×1170×90 | 2100 |
Salient Features
◆ Can be used up to 100°C working temperature.
◆ Filter media is separated by hot melt thread.
◆ All filters are 100% leak tested.
◆ Filter media is fully bonded with frame.
Products Advantage
● Lower pressure drop
● Energy saving
● Lightweight & easy to install
● Interlock design on gasketing to secure the airflow without leaking
Products Application
Many critical applications in healthcare, science and high technology manufacturing require the highest standards of air filtration. HEPA filters are manufactured to the most exacting standards for such applications that include: clean rooms, hospital operating theaters, biological containment laboratories, laminar flow clean benches and safety cabinets, food processing plants, research laboratories.
Trust
◆ We say what we do and we do what we say.
◆ We are open, honest and transparent.
◆ Ethics and integrity are assumed. Anything less is not tolerated.
◆ We meet all our commitments.
◆ We can rely on each other
FAQ
◆ Are you a trading company or manufacturer?
Manufacturer with factory.
◆ Can you produce according to the samples?
Yes, we can produce by your samples or technical drawings.
◆ Can you accept small order?
Yes, we can accept trial orders; It is the starting of business. But according to different product the price may be higher as normal quantity.
