Deep Pleated HEPA Filter

Name: China Deep Pleated HEPA Filter Suppliers, Manufacturers, Factory - Wholesale Price - SNYLI
Brand: SNYLI
SKU: 188050314

The Deep Pleated HEPA Filter is a kind of high-efficiency air filter that uses corrugated aluminum foil separators to separate and support the filter material. Its core filter material is glass fiber, which can filter more than 99.97% of 0.3-micron particles. The partition structure can increase the filtration area, reduce air resistance, and enhance the mechanical strength of the filter element at the same time. It is suitable for ventilation systems with large air volume and high air velocity, and is commonly found in clean rooms, hospitals, electronic factories and other places with strict requirements for air cleanliness.

Send Inquiry

Product Introduction

Snyli Environmental Technology (Shandong) Co., Ltd. is one of the most reliable manufacturers and suppliers of deep pleated hepa filter in China. With abundant experience, we warmly welcome you to wholesale advanced deep pleated hepa filter from our factory. For price consultation, contact us.

Product Description

The Deep Pleated HEPA Filter (High Efficiency Particulate Air Filter) uses high-density glass fiber filter paper folded into a deep and dense pleated structure, significantly increasing the filtration area.
1. Filter material: Glass fiber filter paper, highly efficient in filtering 0.3μm particles, with an efficiency of ≥99.97% (HEPA standard).
2. Pleat design: The Deep Pleat structure provides a larger effective filtration area, reduces wind resistance and prolongs service life.
3. Support frame: Metal outer frame (such as galvanized frame or aluminum frame) to ensure structural stability and prevent deformation.
4. Sealing method: The edges are sealed with polyurethane glue to prevent air leakage.
5. Optional configuration: Some models are equipped with metal protective nets (reinforced front and rear) to enhance mechanical strength and are suitable for high wind speed environments.

Features:
✔ High efficiency and low resistance: The deep pleated design optimizes the airflow distribution, enhancing filtration efficiency while reducing pressure drop.
✔ Long service life: Greater dust holding capacity, suitable for high-dust or long-term operating environments.
✔ Compact design: Deep Pleated HEPA Filter can provide high filtration performance in a limited space, suitable for cleanrooms, medical, electronic manufacturing and other industries.
✔ Diverse options: Customizable in different sizes and efficiencies, suitable for various HVAC or purification equipment.

Common Model

Model	Size W×H×D(mm)	Rated air flow(m³/h)		Initial Pressure(Pa)	Final Pressure(Pa)
Model	Size W×H×D(mm)	Standard	High airflow	Initial Pressure(Pa)	Final Pressure(Pa)
H4BX5-150T5-ZB0	320×320×150	340	540	220/333	500/660
H4PT1-150T5-ZB0	484×484×150	800	1260
H4BX2-150T5-ZB0	630×630×150	1400	2200
H4PT13-150T5-ZB0	915×610×150	2080	3300
H4BX5-220T5-ZB0	320×320×220	400	630
H4PT1-220T5-ZB0	484×484×220	1000	1580
H4BX2-220T5-ZB0	630×630×220	1700	2700
H4BX14-220T5-ZB0	945×630×220	2600	4100
H4PT10-290T5-ZB0	305×610×290	1050	1700
H4BX8-290T5-ZB0	610×610×290	2100	3400

Product Application

Deep Pleated HEPA Filter is widely used in places with strict requirements for air cleanliness due to its advantages such as high efficiency, low resistance, large dust holding capacity and long service life, including various HVAC systems and AHU systems.

1. Medical and pharmaceutical industry
- Hospital operating rooms, icus, and sterile wards: Prevent microbial and particulate contamination to ensure a clean medical environment.
- Pharmaceutical factory (GMP workshop) : Deep pleat HEPA filter can be used for aseptic production, filling lines, and biological laboratories to prevent drug contamination.
2. Electronics and semiconductor manufacturing
- Chip (semiconductor) cleanroom: Filters out fine dust and chemical contaminants to ensure the production of precision electronic components.
- Liquid crystal display panel (LCD/OLED) factory: Separator HEPA filter can prevent particulate matter from affecting the yield of display panels.
3. Food and Beverage industry
- Food processing workshops (such as dairy products and beverage filling) : Prevent microbial contamination and comply with HACCP standards.
- Health care products & pharmaceutical packaging area: Ensure that the products are dust-free and sterile packaged.
4. Industry and Manufacturing
- Automobile painting workshop: Filter paint particles to improve the quality of spraying.
- Precision mechanical processing: Preventing metal dust from affecting high-precision equipment.
