Wooden Chipboard Frame Deep Pleat Filter
The wooden chipboard frame deep pleat filter is a classic filter that uses sturdy and lightweight chipboard wood as the outer frame and expands the filter material area through corrugated separators inside.
Its core advantage lies in its extremely high cost performance: the wooden frame is low-cost and structurally stable, capable of withstanding considerable wind pressure. The separator design effectively reduces air flow resistance, increases dust holding capacity and prolongs service life. It is an economical and reliable air filtration solution for humidity-controlled dry environments in industrial and commercial HVAC systems.
Product Introduction
Snyli Environmental Technology (Shandong) Co., Ltd. is one of the most reliable manufacturers and suppliers of wooden chipboard frame deep pleat filter in China. With abundant experience, we warmly welcome you to wholesale advanced wooden chipboard frame deep pleat filter from our factory. For price consultation, contact us.
Product Description
The Wooden Chipboard Frame Deep Pleat Filter is a very classic and widely used industrial-grade air filter.
Its sturdy wooden frame can withstand high wind pressure and is not prone to deformation. The internal corrugated separator design significantly increases the filtration area, thus ensuring the effective interception of large particle pollutants while offering outstanding advantages such as low resistance, high dust holding capacity and long service life. It is a widely used air filtration product in industrial and commercial ventilation systems.
Pictures
|
Dimensions (mm) |
Rated Airflow (m3/h) |
Initial resistance (Pa) |
Efficiency | Material | |||
| Media | Separator | Sealant | Frame | ||||
|
320x320x220 484x484x220 610x610x150 |
500 1000 1000 |
≤220 | ≥99.99% | Fiberglass | Aluminum foil | PU | Wooden chipboard |
| Non-standard size customization is accepted | |||||||
Product Features
Strong structure, strong deformation resistance
The Wooden chipboard material has a high structural strength. The frame made of it is very sturdy and stable. It can withstand the large wind pressure in the ventilation system and the physical impact during installation and transportation. It is not easy to bend or deform throughout the service life, thus ensuring the sealing reliability of the filter. Throughout its entire service life, it is not prone to bending, twisting or deforming.
Ultimate cost-effectiveness (Core advantage)
Low material cost: The cost of wooden chipboard is lower than that of metals (such as aluminium profiles, galvanized steel sheets).
Mature processing technology: The cutting and assembly processes of wooden frames are very mature and simple, making them easy to be mass-produced.
Lightweight, easy to install and transport
Wooden Chipboard Frame Deep Pleat Filter is lightweight, which makes installation and later replacement and maintenance more effortless and convenient. This advantage is particularly obvious in scenarios where high-altitude operations or batch replacements are required.
Good coordination with separator structure
The sturdy wooden frame provides solid support for the internal corrugated separator (often made of aluminum foil or paper), ensuring that the separator will not collapse under high air volume. This combination perfectly achieves the design goals of increasing the filtration area, reducing the initial resistance and enhancing the dust holding capacity, thereby prolonging the service life of the filter.
Stable and reliable performance
The design of the "separator" ensures the uniformity and stability of the air flow channel, preventing the filter material from being compressed and adhered under the action of wind pressure, thereby ensuring that the filtration performance (efficiency, air resistance) remains stable and predictable throughout its service life.
It should be noted that its main disadvantage is that it is not moisture-proof, so it is not suitable for environments with extremely high humidity. However, in the vast majority of standard commercial and industrial ventilation sites, it is an ideal choice.
Product applications
Wooden Chipboard Frame Deep Pleat Filter can be used in various places.
1. HVAC (Heating, Ventilation and Air Conditioning) system
Central air conditioning units: This is the most mainstream application field.
Central ventilation systems for commercial buildings: office buildings, shopping malls, hotels, schools and other public places.
Industrial plants: Ventilation and air supply systems for various production workshops.
2. Industry and Manufacturing
Coating and painting industry, food and beverage industry, pharmaceutical industry, electronics industry.
3. Public facilities and special occasions
Hospital: Air conditioning fresh air systems and return air systems for areas such as operating departments, wards, and laboratories.
